Magnetic Liquid Traps

Construction: YT Magnetic Liquid Traps consist of a group of strong magnetic grates and a housing outside. An inlet and outlet makes it possible to connect with existing processing line by various connection types. Usually these liquid traps are simply mounted to the existing pipeline via flanged or threaded ends. Easy access is also possible using the quick release clamp. Features: 1. Finishing: Fine polished and well welding to meet food grade. 2. Material of shell: SS304, SS316 and SS316L seamless steel tube 3. Working Temperature: Standard working temperature of liquid trap magnets is ≦ 80℃, but if high temperature is required, we can offer up to 350℃ to meet your special applications 4. Compress resistance: 6 kilograms (0.6Mpa) with quick release clamp while 10 kilograms (1.0Mpa) with flange. 5. As rare earth magnets are extremely powerful and tramp metal is very difficult to remove by hand. We are ready to offer you an easy-clean design. 6. To meet the demand of preserving heat, we offer you a special design adding insulation layer. 7. Customer designs, specifications can be fulfilled.

Application area:

These magnetic liquid traps are suitable for the products that is Liquid, Semi-liquid and air-conveying powder

How to do cleaning?
Magnetic Liquid Traps also should be cleaned periodically for the most efficient performance. Release the cover and hand out the magnetic rods group, and then wipe the tramp metal from SS shell one by one. Use extreme caution and wear gloves during the process.

How to select our products?
Please advise us the above necessary information to make enquiry. If you aren’t in a position to offer these information, please feel free to contact our engineer and acquaint us with the application environment and material condition.


Jacket design for Temperature-preservation
Many products will coagulate when the temperature decreasing. Like Chocolate, it need to preserve high temperature to ensure the free-flowing status. So a design of temperature-preserving Magnetic separator is necessary to obtain an ideal result in filtering ferrous contaminants. That is Jacket design.
